34 Spoke 26 Tricycle Replacement Rim Factories – Gear Differential 33inch,35inch, 37inch – Xiaoni Detail:

Specification

Item Name: Gear Differential
Material: Iron, Steel
Length: 83cm/85cm/89cm/94cm
Brake: Drum Brake 160/180
Usage: For electric tricycle

Models

AXLE TYPE BRAKE SIZE WHEEL FIXING NO.xSIZE OF WHEEL STUD WHEE.REG.DIA(DIM B) DIM.D BEARING MIN WHEEL BEAM SIZE AXLE CAPCITY SPRING SET INSTALLATIONS WEIGHT
LK1218J 420×180 JAP 8xM20x285 221 718 33213  218248 20” ◊150 13T ≤450 350KG
LK1222J 420×220 JAP 8xM20x285 221 738 33213  218248 20” ◊150 13T ≤450 370KG
LK1218I 420×180 ISO 10xM22x335 281 710 33213  218248 20” ◊150 13T ≤450 350KG
LK1222I 420×220 ISO 10xM22x335 ◊150 730 33213  218248 20” ◊150 13T ≤450 380KG
LK118B 420×180 BSF 10×7/8”x335 ◊150 701 33213  218248 20” ◊150 13T ≤450 350KG
LK1220I 420×200 ISO 10xM22x335 281 715 33213  218248 20” 13T ≤450 370KG
LK1622B 420×220 BSF 10×7/8”x335 281 721 218248  220149 20” 16T ≤450 420KG
LK 1622I 420×220 ISO 10xM22x335 281 721 218248  220149 20” ◊150 16T ≤450 420KG
LK 1822I 420×220 ISO 10xM22x335 281 721 218248  220149 20” ◊150 18T ≤450 450KG
LK12018I 420×180 ISO 10xM22x335 281 710 33213  218248 20” ø127×18 12T ≤450 350KG
LK12018J 420×180 JAP 8xM20x285 221 718 33213  218248 20” ø127×18 12T ≤450 340KG
LK12018B 420×180 BSF 10×7/8”x335 281 701 33213  218248 20” ø127×18 12T ≤450 350KG
LK12022I 420×220 ISO 10xM22x335 281 730 33213  218248 20” ø127×18 13T ≤450 370KG
LK16022I 420×220 ISO 10xM22x335 281 721 218248  220149 20” ø127×18 16T ≤450 430KG
LK17022I 420×220 ISO 10xM22x335 281 721 218248  220149 20” ø127×18 17.5T ≤450 430KG
LK1188I 311×178 ISO 10xM22x335 176 690 33213  218248 15” ø127×18 10T ≤390 260KG
LK1518I 311×178 ISO 10xM22x335 176 690 33213  218248 15” ø127×18 15T ≤390 300KG

When you order the differential rear axle from us, please provide the following parameters to us, so that we can provide the drawings as per the parameter we receive. And this includes,
1. Total length of axle required;
2. Leaf spring distance (hole center to hold center);
3. Axle loading request and dimension of the brake drum;
4. Wheel hub seam allowance where it connects the motor.
5. Internal end distance;
6. The Hub PCD size which connects your wheels.
7. Gearbox with reduction ratio, we have the gear ratio ranging from 6 to 25.
